D120 Varibore Hexagon Collet
D Type Collet for 1st Operation Work
Key Features
- 1/8" Range per Collets
- Sizes Up To 50.8mm Across Flats
- Smooth Bore as Standard, Other Finishes Available
- Special Profiles Available
Description
D120 Varibore hex collets are to suit 54mm capacity collet chucks. Also known as V120, these collets have a 3.175mm range. Supplied smooth as standard we can supply with alternate finishes and in special profiles. D120 suit the following collet chucks: Klamp CRL54 Klamp CRS54 Klamp QCRL54 Crawford CDC54 Crawford CDC-54-S Crawford QC-54
Estimated delivery: 2-3 Weeks (subject to availability)
Dimensions
| # | Part No | Range (mm) | Range (inch) | Bore | Price | ||
|---|---|---|---|---|---|---|---|
| 1 | D120X-D69 | 3.17 - 6.35 | 1/8 - 1/4" | Smooth | £ Price on application | n/a | |
| 1 | D120X-D70 | 6.35 - 9.52 | 1/4 - 3/8" | Smooth | £204.42 | ||
| 1 | D120X-D71 | 9.52 - 12.7 | 3/8 - 1/2" | Smooth | £204.42 | ||
| 1 | D120X-D72 | 12.7 - 15.87 | 1/2 - 5/8" | Smooth | £204.42 | ||
| 1 | D120X-D73 | 15.87 - 19.05 | 5/8 - 3/4" | Smooth | £204.42 | ||
| 1 | D120X-D74 | 19.05 - 22.22 | 3/4 - 7/8" | Smooth | £204.42 | ||
| 1 | D120X-D75 | 22.22 - 25.4 | 7/8 - 1" | Smooth | £204.42 | ||
| 1 | D120X-D76 | 25.4 - 28.57 | 1 - 1 1/8" | Smooth | £204.42 | ||
| 1 | D120X-D77 | 28.57 - 31.75 | 1 1/8 - 1 1/4" | Smooth | £204.42 | ||
| 1 | D120X-D78 | 31.75 - 34.92 | 1 1/4 - 1 3/8" | Smooth | £204.42 | ||
| 1 | D120X-D79 | 34.92 - 38.1 | 1 3/8 - 1 1/2" | Smooth | £204.42 | ||
| 1 | D120X-D80 | 38.1 - 41.27 | 1 1/2 - 1 5/8" | Smooth | £204.42 | ||
| 1 | D120X-D81 | 41.27 - 44.45 | 1 5/8 - 1 3/4" | Smooth | £204.42 | ||
| 1 | D120X-D82 | 44.45 - 47.62 | 1 3/4 - 1 7/8" | Smooth | £204.42 | ||
| 1 | D120X-D83 | 47.62 - 50.8 | 1 7/8 - 2" | Smooth | £204.42 |
