Series-9 Clamps
Low Profile Cam Action Clamps
Key Features
- Low Profile for Good Clearance
- Cam Action for Fasr Clamping
- Available Smooth or Serrated
- Faces are in 1mm Increments from centreline
Description
Adjustable low-profile clamp. Actuated using a Cam screw, it is quick and easy to use but is adjustable with each face being 1mm further away from centreline. This allows for one clamp to hold parts varying up to 9.4mm by rotating the clamp. Four sizes available in both metric and serrated and metric and imperial.
Estimated delivery: 3-5 Working Days (subject to availability)
Dimensions
| # | Part No | Type | Grip Type | Clamp Force (N/lbs) | Bolt | Distance from Centre Line (mm) | Price | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | 95110 | Metric | Smooth | 17800 | M12 | £44.06 | |||
| 1 | 95115 | Metric | Serrated | 17800 | M12 | £47.46 | |||
| 1 | 95120 | Metric | Smooth | 17800 | M12 | £48.50 | |||
| 1 | 95125 | Metric | Serrated | 17800 | M12 | £51.90 | |||
| 1 | 95130 | Metric | Smooth | 17800 | M12 | £54.71 | |||
| 1 | 95135 | Metric | Serrated | 17800 | M12 | £58.11 | |||
| 1 | 95140 | Metric | Smooth | 17800 | M12 | £60.03 | |||
| 1 | 95145 | Metric | Serrated | 17800 | M12 | £63.43 | |||
| 1 | 90110 | Imperial | Smooth | 4000 | 1/2-13 | £ Price on application | n/a | ||
| 1 | 90115 | Imperial | Serrated | 4000 | 1/2-13 | £ Price on application | n/a | ||
| 1 | 90120 | Imperial | Smooth | 4000 | 1/2-13 | £ Price on application | n/a | ||
| 1 | 90125 | Imperial | Serrated | 4000 | 1/2-13 | £ Price on application | n/a | ||
| 1 | 90130 | Imperial | Smooth | 4000 | 1/2-13 | £ Price on application | n/a | ||
| 1 | 90135 | Imperial | Serrated | 4000 | 1/2-13 | £ Price on application | n/a | ||
| 1 | 90140 | Imperial | Smooth | 4000 | 1/2-13 | £ Price on application | n/a | ||
| 1 | 90145 | Imperial | Serrated | 4000 | 1/2-13 | £ Price on application | n/a |
