Swivel Shoulder Clamping Screw PT17B
Flat End
Description
Swivel Shoulder Clamping Screw PT17B FLAT END Material: Bolt: SCM435(JIS) / 34CrMo4(DIN) Ball: SUJ2(JIS) / 100Cr6(DIN) Heat treated: Bolt: HRC 28°~32° Ball: HRC 62° Surface finish: Black Oxide.
Leave
Estimated delivery: 5-7 Working Days (subject to availability)
Dimensions
| # | Part No | Thread | Length (mm) | Price | ||
|---|---|---|---|---|---|---|
| 1 | PT17B-0615 | M 6 | 14 | £6.19 | ||
| 1 | PT17B-0625 | M 6 | 23 | £6.19 | ||
| 1 | PT17B-0635 | M 6 | 33 | £6.19 | ||
| 1 | PT17B-0820 | M 8 | 18 | £6.65 | ||
| 1 | PT17B-0830 | M 8 | 28 | £6.65 | ||
| 1 | PT17B-0840 | M 8 | 38 | £6.65 | ||
| 1 | PT17B-0850 | M 8 | 50 | £6.77 | ||
| 1 | PT17B-1025 | M10 | 24 | £7.94 | ||
| 1 | PT17B-1040 | M10 | 39 | £8.17 | ||
| 1 | PT17B-1060 | M10 | 59 | £8.64 | ||
| 1 | PT17B-1230 | M12 | 30 | £11.32 | ||
| 1 | PT17B-1245 | M12 | 45 | £12.02 | ||
| 1 | PT17B-1265 | M12 | 65 | £12.84 | ||
| 1 | PT17B-1280 | M12 | 80 | £13.07 | ||
| 1 | PT17B-1640 | M16 | 39 | £14.47 | ||
| 1 | PT17B-1650 | M16 | 49 | £15.05 | ||
| 1 | PT17B-1665 | M16 | 64 | £15.87 | ||
| 1 | PT17B-1690 | M16 | 89 | £17.27 | ||
| 1 | PT17B-20050 | M20 | 50 | £18.20 | ||
| 1 | PT17B-20080 | M20 | 80 | £20.19 | ||
| 1 | PT17B-20100 | M20 | 100 | £21.70 | ||
| 1 | PT17B-24060 | M24 | 60 | £20.65 | ||
| 1 | PT17B-24090 | M24 | 90 | £23.57 | ||
| 1 | PT17B-24120 | M24 | 120 | £28.35 |
